Production Lines

Cut To Length Line +Plus

Project Specific Design, Turnkey Solutions...

Besides these specifications with Our +Plus Lines, We also provide the Quality of Cutting with Accurate and Fast Cutting Speed even for Special Coils;  Stainless Steel, Aluminum, Copper, Chrome Coated, Brass, Bronze…

SACFORM’s Cut to Length Line+Plus Machinery is a certain solution for various Materials and Dimensions, for your special  Projects with Heavy Industries.

Model Material Width (mm) Weight Working Type Stacking Line Speed
CTL1602 0.3 2 1600 10 – 15 – 20 Flying / Rotary -Shear 3000 / 6000 60 m / min
CTL1603 0.5 3 1600 10 – 15 – 20 Flying / Rotary -Shear 3000 / 6000 50 m / min
CTL1604 0.8 4 1600 15 – 20 – 25 Flying / Rotary -Shear 3000 / 6000 40 m / min
CTL1606 1 6 1600 15 – 20 – 25 Flying / Rotary -Shear 3000 / 6000 30 m / min
CTL1608 2 8 1600 15 – 20 – 25 Flying / Rotary -Shear 3000 / 6000 26 m / min



Model Material Width (mm) Weight Working Type Stacking Line Speed
CTL2002 0.3 2 2000 10 – 15 – 20 Flying / Rotary -Shear 3000 / 6000 60 m / min
CTL2003 0.5 3 2000 10 – 15 – 20 Flying / Rotary -Shear 3000 / 6000 50 m / min
CTL2004 0.8 4 2000 15 – 20 – 25 Flying / Rotary -Shear 3000 / 6000 40 m / min
CTL2006 1 6 2000 15 – 20 – 25 Flying / Rotary -Shear 3000 / 6000 30 m / min
CTL2008 2 8 2000 15 – 20 – 25 Flying / Rotary -Shear 3000 / 6000 26 m / min
  • Easy Operation with High Level Automation
  • High Quality and Maximized Efficiency with Minimized Operation Cost
  • High Capacity with Compact Design
  • Project-Specific Straightening Designs for Top Quality Surface Accurracy
  • Precision Production with Material-Specific Quality Rollers and Transfer System
  • High Quality Cutting without Scrap
  • Automated Stacking System Solutions
